HKS 13001-AT011 Intercooler Kit for TOYOTA GR Yaris Gen2 GR-DAT (GXPA16) 2024-
Description HKS 13001-AT011 Intercooler Kit for TOYOTA GR Yaris Gen2 GR-DAT (GXPA16) 2024-
The HKS Intercooler Kit is specifically developed for the Toyota GR Yaris Gen2 DAT (GR-DAT / 8-speed automatic). Designed as a direct OEM replacement, the upgraded core features increased height and thickness to provide stable and improved cooling performance under higher load conditions.
An optimized fin design maintains cooling efficiency while ensuring sufficient airflow through the core, minimizing any negative impact on engine coolant temperature. To support increased power output, the inlet and outlet tank diameter has been enlarged from the stock d-45 to d-50. Reinforced 4-ply hoses replace the OEM 1-ply hoses, enhancing durability and resistance to damage.
An HKS logo spray stencil is included for a subtle visual enhancement.
- Direct OEM replacement design
- Increased core height and thickness
- Optimized 12-row fin and 11-row tube configuration
- Enlarged inlet/outlet diameter (d-45 - d-50)
- Reinforced 4-ply hoses
- Aluminum inlet and outlet tanks
Specifications:
- Core Size: L645 x W205 x H105 mm
- Fin Design: 12-row
- Tube Design: 11-row
- Inlet Tank Material: Aluminum
- Outlet Tank Material: Aluminum
- Hose Specification: 4-ply
Performance Data:
- Peak Power (HKS): 196.5 kW (267.2 PS) at 6400 rpm (+3.6 kW / +4.8 PS)
- Peak Power (OEM): 192.9 kW (262.4 PS) at 6400 rpm
- Peak Torque (HKS): 403.6 Nm (41.1 kgf·m) at 4280 rpm (+10.9 Nm / +1.1 kgf·m)
- Peak Torque (OEM): 392.7 Nm (40.0 kgf·m) at 4260 rpm
- Maximum Power Gain within RPM Range: up to +6.0 kW (+8.2 PS)
Remarks:
- Exclusive for GR-DAT (8-speed automatic) models
- Compatible with vehicles equipped with Cooling Package and factory optional sub radiator
- When used with intercooler water spray system, optional Water Spray Bracket (13999-AT001) is required
- Not compatible with HKS piping kits (13002-AT001 / 13002-AT002)
Original: $2,017.76
-70%$2,017.76
$605.33
